機箱機柜鈑金加工是使用多種不一樣的制造方法將金屬板成型為所需形狀的過程，包括切割、折彎、焊接到表面處理、組裝等很多步驟。通常，從機箱機柜鈑金到金屬產品的過程要從制圖開始，制圖完成后，經過鈑金制造過程，制成各種各樣的零件。

　　Chassis and cabinet sheet metal processing is the process of forming metal plates into the desired shape using various manufacturing methods, including cutting, bending, welding to surface treatment, assembly, and many other steps. Usually, the process from chassis and cabinet sheet metal to metal products starts with drawing, and after the drawing is completed, various parts are made through the sheet metal manufacturing process.

　　激光切割激光切割是切割機箱機柜板材的，這是一種非常快速而精確的切割方法，并且不受模具的限制，如圖1.5mm的板材，切割出來平整光滑無毛刺。

　　Laser cutting is the preferred method for cutting chassis and cabinet boards. It is a very fast and precise cutting method that is not limited by molds. As shown in Figure 1.5mm, the board is cut flat, smooth, and free of burrs.

　　數控轉塔沖床沖壓是在鈑金行業中切孔的另一種方法，利用金屬沖頭沖擊板材打孔，適用于大規模生產，遇到圓孔、多孔等規律形狀的話，數控轉塔沖床使用模具沖壓能快速實現。

　　CNC turret punch punching is another method of cutting holes in the sheet metal industry. It uses a metal punch to impact the sheet metal and punch holes, which is suitable for large-scale production. When encountering regular shapes such as circular holes and multiple holes, CNC turret punch punching can be quickly achieved using molds.

　　折彎由于折彎的復雜性，這可能是機箱機柜鈑金加工金屬制造中困難的步驟，工程師必須對金屬的彎曲屬性非常熟悉。

　　Due to the complexity of bending, it may be the most difficult step in metal manufacturing for chassis and cabinet sheet metal processing, and engineers must be very familiar with the bending properties of metals.

　　焊接焊接工藝是根據產品的生產性質、圖紙和技術要求，結合現有條件，將切割、折彎后的鈑金件進行焊接成箱體。

　　The welding process is based on the production nature, drawings, and technical requirements of the product, combined with existing conditions, to weld the cut and bent sheet metal parts into a box.

　　噴塑（表面處理）焊接成型的箱體在進行試裝后轉序到噴涂車間進行粉末噴塑。粉末噴塑是將靜電粉末涂料噴涂到工件上，在靜電作用下，粉末會均勻吸附于工件表面，再經過高溫烘烤形成終的涂層。

　　The box body formed by spraying (surface treatment) welding is transferred to the spraying workshop for powder spraying after trial assembly. Powder coating is the process of applying electrostatic powder coating onto a workpiece. Under the action of static electricity, the powder is uniformly adsorbed onto the surface of the workpiece, and then baked at high temperatures to form the final coating.

　　噴塑后的產品表面防塵防水，其附著力、耐腐蝕、耐老化等方面優于噴漆工藝，適合戶外各種惡劣環境。當沒有特殊要求時，它是的表面處理方法。?

　　The surface of the product after spraying is dustproof and waterproof, and its adhesion, corrosion resistance, aging resistance, and other aspects are superior to the spray painting process, making it suitable for various harsh outdoor environments. When there are no special requirements, it is the preferred surface treatment method.?

　　打印部分機箱機柜在噴塑完成后會直接轉序到組裝進行裝配，但也有部分需要印LOGO或者圖案的，需要轉序到打印室進行打印。

　　After the spray coating is completed, some chassis and cabinets will be directly transferred to assembly for assembly, but there are also some that require printing logos or patterns and need to be transferred to the printing room for printing.

　　UV平板打印機在工業打印機中可謂是一匹黑馬，相比傳統的絲印工藝，其功能十分強大：無需排版，可以適應不同大小件打印，一次成型，圖案美觀清晰，防曬防水，重要的是無異味。

　　UV flatbed printers are a dark horse among industrial printers. Compared to traditional screen printing processes, their functions are very powerful: they do not require typesetting, can adapt to printing of different sizes, can be molded in one go, have beautiful and clear patterns, are sun resistant and waterproof, and most importantly, are environmentally friendly and odorless.

　　數控點膠

　　CNC glue dispensing

　　數控點膠與傳統人工貼條相比，粘接牢固，表面光滑美觀，一次成型無接縫，附著力強，彈性好，防水防塵。

　　Compared with traditional manual adhesive strips, CNC glue dispensing has firm adhesion, smooth and beautiful surface, seamless one-time molding, strong adhesion, good elasticity, waterproof and dustproof.

　　裝配機箱機柜成品一步就是裝配了。所有的鈑金件都已準備就緒，將其組裝起來就好了。

　　The final step in assembling the finished chassis cabinet is assembly. All the sheet metal parts are ready, just assemble them together.
